TR-9100 Digital UHF 100CH TRUE DIVERSITY Wireless Microphone System

  • Product Feature
  • Product Specification
APPLICATION
  • Class Room 、Playground、Hall
  • PA System、Long Distance Using
  • Church、Temple
Digital Circuit , Analog Signal , Auto Search Channel
  • When setting up the channel , the CUP will calibrate the logic code automatically.Only when the logic codes from the CPU and the transmitter match will the signals be transferred.This extra step of logic codes calibration will reduce the likelihood of signal disruption.
  • LCD to indicate the information.
  • Stage Bright of LCD. easy to show ON / OFF.
  • Microphone bettery indicator show in LCD.
  • With HI / LO select for transmit power.

Function

Specifications

Frequency Range

Digital UHF PLL 100CH (510-950MHz)
Frequency range depend on the regulations

Oscilator

PLL Synthesized,Preset 100 selectable channels

Frequency Bandwidth

30M Hz

Frequency Stabilization

>±50KHz

Dynainic Range

>90dB

T.H.D

<0.5%

Frequency Response

40Hz-15000Hz ±3dB

Audio Output

Balance (XLR) / Onbalance (6.3Øjack)
Receiver Mode Dual Channel , True-Diversity
Power Supply DC12V-15V/1 A
Consume Power 5WATT
S/N Ratio >107dB
Receiving Sensitivity 5dBuV
Antenna Power Output 9V/100mA
Receiver Dimension 420 x 152 x 45mm
Receiver Weight 1.6Kg
Transmit Power 30mW(Max)
Modulation Mode FM
Max Deviation ±25KHz

Battery Voltage

3V (2x1 .5V AA Battery)

Continuous Using

5-8 hour

Attention : According to the reality provide
