TA-680 8" 200W Portable PA System

  • Product Description
  • Product Feature
  • Product Specification

APPLICATION

Classroom presentations
Indoors/ outdoors events
Religious activities
Public speech campaign
Seminar
street artist

3 Patents

  • M463016 New Design Shape.
  • M463954 Double Power Out-Put.
  • M402573 LED Ring to indicate the battery's life for microphone.

Double Power Out-Put(M463954)
Class D Max 200w+Max 200w
If you connect with Passive Speaker(8Ω)
The power out-put will be double Max 200w+Max 200w

5 Characteristic

  • Light Weight Case Easy Operating.
  • High Power Output Low Energy Consumption.
  • Double Power Out-put, connect with the passive speaker by cable, the power will be doubled.
  • Smart Power Charging circuit.
  • All made in Taiwan.

Function

Specification

Power Output

Class D Max 200w+Max 200w Double Power Out-Put

T.H.D.

<0.5%

Echo

Echo effect control

Frequency Response

60Hz~20KHz±3dB

Speaker

8” full range speaker + Tweeter Horm

Power Supply

100v-240v

Battery

12V / 5 Ah × 2

Battery Power Indicator

 4-LED Indicator for the Battery Power

Charging Time

10-12 hours charging

Operating Time

5-8 hours consecutive use

Receiver Module

PLL Synthesized, TR-332 UHF 32CH or TR-316 UHF 16CH

Wireless Mic

Handheld、Lavalier、Headset

Wired Mic

All wired Microphone

Player CD / USB / SD player, DVD player (option), TR-MP3B(option), TR-MPS (option)

Audio Input

XLR & 1/4 (6.3mm) Combo Input and RCA Input

Audio Output

1/4 (6.3mm) Double Power Output and RCA Output

Dimensions

340 × 330 × 545 mm

Weight

15Kg

Exterior Color

Black

Attention: According to the reality provide
