TA-680 8" 200W Portable PA System

  • Product Description
  • Product Feature
  • Product Specification

APPLICATION

Classroom presentations
Indoors/ outdoors events
Religious activities
Public speech campaign
Seminar
street artist

3 Patents

  • M463016 New Design Shape.
  • M463954 Double Power Out-Put.
  • M402573 LED Ring to indicate the battery's life for microphone.



5 Characteristic

  • Light Weight Case Easy Operating.
  • High Power Output Low Energy Consumption.
  • Double Power Out-put, connect with the passive speaker by cable, the power will be doubled.
  • Smart Power Charging circuit.
  • All made in Taiwan.
  • Lithium Battery for option.

Function

Specification

Power Output

Max200W

T.H.D.

<0.5%

Echo

Echo effect control

Frequency Response

60Hz~20KHz±3dB

Speaker

8” full range speaker + Tweeter Horm

Power Supply

Switching Power (100v-200v / 200v-250v)

Battery

12V / 5 Ah × 2 / Lithium Battery 12V /7.8Ah× 2 (option)

Battery Power Indicator

 4-LED Indicator for the Battery Power

Charging Time

10 hours / 10 hours (Lithium Battery)

Operating Time

4-8 hours / 8-12 hours (Lithium Battery) consecutive use

Receiver Module

PLL Synthesized, TR-332 UHF 32CH or TR-316 UHF 16CH

Wireless Mic

Handheld、Lavalier、Headset

Wired Mic

All wired Microphone

Player CD / USB / SD player, DVD player (option), TR-MPS (option)

Audio Input

XLR & 1/4 (6.3mm) Combo Input and RCA Line Input

Audio Output

1/4 (6.3mm) Double Power Output and RCA Line Output

Dimensions

340 × 330 × 545 mm

Weight

15Kg /12.5kg (Lithium Battery)

Exterior Color

Black

Attention: According to the reality provide
